Drolet Escape 1500-I Wood Insert With Faceplate DB03137
by Drolet
Original Price
$1,699.00
Current Price
$1,449.00
Make Your House Comfortable All Year Long With the Drolet Escape 1500-I Wood Insert
Don't let the cold keep you indoors this winter – warm up your home with the Drolet Escape 1500-I Wood Insert! This powerful and eco-friendly wood insert provides plenty of heat to keep you comfortable all winter long. With only 1.26 g/h of particulate emissions, it meets EPA standards, so you can feel good about keeping your family warm. With up to 65,000 BTU/h of heating power, the Escape 1500 is perfect for homes up to 1,800 ft². Order yours today!
Included: 29'' x 44'' faceplate, blower, ceramic glass, ash lip, air damper
Options: firescreen, fresh air intake
Drolet Escape 1500-I Wood Insert DB03137 Features:
- Burn time up to 6 hours
- Up to 18'' logs
- 1.9 ft³ firebox
- Robust 5/16'' steel
- EPA certified
- Proudly made in Canada
- Limited lifetime warranty
- Firebox lined with refractory bricks for better heat distribution
- Optimum efficiency : 78 %
- Average particulate emissions rate : 1.26 g/h
- Steel thickness – top : 5/16"
- High-efficiency certified appliance : Yes, EPA 2020 approved
- Recommended heating area-ft² : 500 - 1,800
- Blower included
Drolet Escape 1500-I DB03137 Specifications:
| Fuel type | Dry cordwood (16" recommended) |
| Recommended heating area-ft² | 500 - 1,800 |
| Overall firebox volume-ft³ | 1.9 |
| EPA loading volume-ft³ | 1.44 |
| Maximum burn time | 6 h |
| Maximum heat output-dry cordwood | 65,000 BTU/h (19 kW) |
| Overall heat output rate |
15,650 BTU/h (4.6 kW) to 23,300 BTU/h (6.83 kW)
|
| Average overall efficiency (dry cordwood) | 70 % (HHV) (5) |
| Optimum overall efficiency | 78 % |
| Optimum heat transfer efficiency | 74 % |
| Average particulate emissions rate | 1.26 g/h |
| Average CO (10) | 58 g/h |
| Combustion technology | Non-catalytic |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Maximum log length | 18" |
| Log positioning | Loading over width |
| Chimney diameter | 6" |
| Flue outlet diameter | 6" |
| Type of chimney | Liner - ULC-S635, CAN/ULC-S640, UL1777 |
| Minimum chimney height (feet) | 12' |
| Baffle type | High quality vermiculite |
| Approved for a mobile home installation | No |
| Door type | Single, glass with cast iron frame |
| Glass type | Ceramic glass |
| Glass surface – dimensions (Width X Height) | 15 3/4" x 9 3/4" |
| Glass air-wash system | Yes |
| Premium quality blower included (CFM) | 144 |
| Overall dimension (Height) | 21 1/4" |
| Overall dimension (Width) | 27 1/4" |
| Overall dimension (Depth) | 22 3/8" |
| Door opening – dimension (Height) | 8 3/4" |
| Door opening - dimension (Width) | 17 1/4" |
| Firebox – dimension (Height) | 11 7/8" |
| Firebox – dimension (Width) | 19 5/8" |
| Firebox – dimension (Depth) | 13 1/2" |
| Firebox lined with refractory bricks for better heat distribution | Yes |
| Stainless-steel secondary-air system improving gas combustion | Yes |
| Adjustable threaded legs | Yes |
| Steel thickness – body | 3/16" |
| Steel thickness – top | 5/16" |
| Fireplace opening – minimum (Height) | 21 1/2" |
| Fireplace opening – minimum (Width) | 27 1/2" |
| Fireplace opening – minimum (Depth) | 12 3/4" |
| USA standard (emissions) | EPA |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA standard (safety) | UL 1482, UL 737 |
| Canadian standard (safety) | ULC S628 |
| Tested and listed as per applicable standards | By an accredited laboratory (CAN/USA) |
| Warranty | Limited lifetime |
Drolet Escape 1500-I Wood Insert Clearance Requirements:
| Clearance – top (measured from the platform on which the appliance is installed)** | 84" |
| Clearance – combustible side mantle to unit | 9" |
| Clearance – combustible top mantle to unit | 27" |
| Clearance – combustible side wall to unit | 16" |
| Clearance – minimum floor protection in front of the appliance | 16" |
| Clearance - from the top of the unit to the shelf | |
| Clearance – from the top of the insert to the shelf | 27" |
Drolet Escape Fireplace Insert Manual:
Click Here for Installation Manual
Drolet Escape 1500-I Wood Insert DB03137 Specification Sheet:
